产品特点:
H.264 video compression format, high compression ratio, clear image, 1-4 channels video input, 1 channel CVBS output
Adopt ADI US professional 10bits chip video decoder processor, the image quality of our products boost level by 4 times than that of 8bits under the same stream.
Each video channel is attached with an independent video decoder to avoid disturbing from each other.
HD real time recording: 100f/s (PAL); 120f/s (NTSC). Recording resolution: CIF/ 2CIF/ D1 optional
Maximum support 2CH of D1 + 2CH of CIF real time recording / playback
Professional car power supply design, support 8V~36V DC wide voltage range input (instaneous voltage can up to 70V)
Provide a strong circuit protection .including DC out protection, reverse voltage protection, overload protection, short circuit protection, over temperature protection etc.
Support mobilephone monitoring
Support various recording modes: auto recording, alarm recording (open/close the door), timed recording manual recording etc.
Support video packing time setting
G.726 audio compression format
4CH audio input, 1CH audio output.
Support remote voice surveillance and remote voice talkback function
6CH alarm input (Level input), 1CH alarm output (Relay output)
Support pre-recording function, 15 seconds pre-recording of alarm, recording time after alarm can be adjusted in between 30 sec ~ 30 min
Support the setting of remain storage space alarm function, overspeed alarm, acceleration alarm, motion detection alarm
Communication interface: RS232 , RJ45。ODM expansion design
Support GPS, G-sensor, Gyro-sensor acceleration transducer
Support 3G wireless transmission functions: WCDMA, CDMA2000, TD-SCDMA, GPRS, EDGE, WiFi wireless transmission (support WiFi automatic download and resume from break point) are optional
Support 3G remote fuel cut-off and power-off
The video file format is ASF. The file can be played by general media player VLC or our customized software which support 1 channel or 4 channels synchronous playback
Data storage: maximum support 2 pcs 64G SD card, Using Japanese origin SD card connector canguarantee the fluency of data reading.
Data redundancy storage technology
Quick start-mode: the device will turn to working in 25 sec after power on. Other start- or close- mode including ACC on, timed turn on/off, manual boot/shutdown the device.
Energy- efficient design, the power consumption is less than 5W with normal operating state Support local and remote PTZ control
All electronic components conform to industrial standard through the entire design, including the special connectors dedicated for mobile DVR.
With anti-vibration, anti-high temperature protection and low temperature pre-heated function, the quality of video files is always guaranteed. Working temperature: -20℃ to +70℃
Industrial grade design: easy installation operation
